SOCO HVS-375AC

This cold saw machine features numeric control, high precision, high speed with loading magazine for bar, tube and various extruded and non-extruded profiles.

Request a Quote

    Your Name*

    Your Email*

    Telephone*

    Company Name*

    SKU: HVS-375AC Categories: ,

    AC Line

    • Semi-Automatic operation
    • Straight and angle cutting
    • Air lifting system for angle cut setting

    Performance

    • Vertical Slide for maximum cutting power and rigidity
    • Standard with Speed Inverter for speeds of 22 – 1DBRPM
    • Electric Servo Feeding for +/- 0.05 – 0.1mm Cutting Length precision (per stroke)
    • Capacity up to 127mm in Tube and 10Dmm in Solid Bars
    • Superior Gear Box design for maximum machine life and performance
    • Flexible Gripper Feeding + Floating Carriage allow for maximum feeding precision even in material which is not perfectly straight
    • Cutting Examples
    • O.D 50mm solid bar, L = 150mm, cycle time is 28sec
    • O.D 75mm steel tube, L = 139mm, cycle time is 11.5sec
    Specification / Model HVS-375AC
    Cutting Angle 90° 45°
    Round Tube ?110 ?110
    Square Tube 110 x 110 95 x 95
    Solid Round Bar ?75 ?55
    Solid Square Bar 70 x 70 50 x 50
    Type A B
    Main Motor (HP / Pole) 3/6 2/8
    Arbor RPM (60Hz) 72/32 55/22
    HSS Saw Blade Size (mm) ?250 ~ ?370 HSS – Arbor Hole ?32. Pin Hole 2 x ?11x 63 PCD
    TCT Saw Blade (+) ?285 – ?360 – By Request (+)
    Hydraulic System 2HP-4P Pump. Working Pressure 25 – 35kg/cm²
    Cooling System 0.125HP Water Pump. Automatic Coolant Circulation
    Total Power
    • 4.0KW ( Motor 3HP )
    • 3.2KW ( Motor 2HP )
    Weight (Kg) 400
    Dimensions (cm)
    (L x W x H)    		 700 x 1500 x 1750 (Standard)
    • Roller Type Material Input Stand
    • Roller Type Material Output Stand and adjustable length gauge and stopper
